  Material:
Stainless Steel & Anodized Aluminum Mounting Method: Spring Clips Flange Diameter: 3.15" Depth: 1.2" Suitable Environments:  Dry,  Damp,  WetEmitting Angles: Flood  Input:
6 to 30VDC Power: 4W Protection: Reverse Polarity, Transient  Architectural
Industrial Marine *spring clip version
**high power version |
SMART No external drivers required. i2Systems SmartDriver technology inside every fixture. Retrofit compatible. VERSATILE Connects directly to 12/24V DC systems. Light output remains continuous over the entire 6 to 30V DC range. EFFICIENT Only 4 Watts per fixture. 50,000 hour operating life. BRIGHT Comparable light distribution and output to conventional sources. Produces even light, no LED dots or hot spots. COOL Advanced thermal technology and highly efficient design means cool to the touch operation. STYLISH 5 finishes available. UNIQUE High Brightness WARM WHITE. IDEAL FOR: � General Illumination � Under counter lighting � Direct retrofit for halogen based applications 0 TO 100% DIGITAL DIMMING With a single expansion module, dim up to 18 fixtures of any color.  |
|
|
|
 Spring Mount
AP - (X) HB - SDI - (Y) 1 LED Color (X):
 1 White 2 Warm White |
Finish (Y):
     1 Polished Chrome
2 Polished Gold 3 Powder Coated White 4 Brushed Nickel 5 Powder Coated Off-White |
