2 NM Stern Lamp Series: 2010 3

BSH approved navigation lamp. Anti-magnetic and saltwater proof. Housing 'snaps' to base without screws. A hanging bulb and contacts in the upper area of each lamp prevents corrosion of the contacts.

Black Housing

Part Number:
2LT 002 984-321
USA: 002 984-325
AUS: 2851
NZ: 2851

White Housing

Part Number:
2LT 002 984-371
USA: 002 984-375
AUS: 2851W
NZ: 2851W

Specifications

Material Description

Shock proof, sturdy plastic light housing and base plate, UV resistant

Bulb

12V / 10W resp. 25 W, socket BAY 15d included

Installation

Combined screw flatp lug connection 6.3 mm

Protective System

According to IP 55 (DIN 40050)

Mounting

Direct attachment, with bolts or self-tapping screws, 5 mm. With universal mount 8HG 122 452-001 to all attachment surfaces, with rail mount
8HG 003 141-001
or attachment base
8HG 005 798-001/011

Minimum visible Distance

2 NM

Cable Entry

through base plate with cable grommet
